Zyxel

Zyxel LTE3301-PLUS

Name: Zyxel LTE3301-PLUS
Brand: Zyxel
SKU: LTE3301-PLUS

Released Dec 2020

Wi-Fi

WiFi 5 (802.11ac)

RAM

256 MB

CPU Cores

LAN Ports

At a glance

Highlights

Wi-Fi WiFi 5 (802.11ac)

Supports IPv4, IPv6, WiFi (802.11a), WiFi (802.11b), WiFi (802.11g), WiFi 4 (802.11n), WiFi 5 (802.11ac)

Dual-band

2.4 GHz · 5 GHz

4 × Gigabit LAN

1 Gigabit WAN port

Mesh: No

Compatible with mesh networking

Built-in VPN

Server: IPSec, L2TP, PPTP

Every detail

Full Specifications

General

10 specs

Manufacturer

Zyxel

Model

LTE3301-PLUS

Full Name

Zyxel LTE3301-PLUS

Homepage

Open website

Release Date

2020-12-01

Currently Sold

Manufacturer Support

Operating System

Proprietary OS

Custom ROM

OpenWRT

Mesh Integration

Hardware

7 specs

Processor

MediaTek MT7621AT

Processor Speed (MHz)

880

CPU Cores

RAM (MB)

256

Flash (MB)

128

External Antennas

Internal Antennas

Connectivity

13 specs

Network Standards

IPv4 IPv6 WiFi (802.11a) WiFi (802.11b) WiFi (802.11g) WiFi 4 (802.11n) WiFi 5 (802.11ac)

Operating Modes

Router

2.4 GHz Support

Yes

5 GHz Support

Yes

6 GHz Support

Gigabit WAN Ports

Gigabit LAN Ports

LAN Aggregation

WAN Aggregation

USB Ports

USB-A (2.0) (1)

WAN Connection Types

Automatic IP PPPOE Static IP

Cable Modem

Fibre Modem

Core Features

6 specs

VPN Servers

IPSec L2TP PPTP

Mobile App

Zyxel Air

WPS Button

Yes

Reset Button

Yes

Power Switch

Yes

LED Switch

Physical

10 specs

Weight (g)

500.00

Length (mm)

115.00

Width (mm)

210.00

Height (mm)

33.00

110V Power Supply

Yes

220V Power Supply

Yes

Horizontal Positioning

Yes

Vertical Positioning

Wall Mountable

Package Content

Power adapter, Ethernet cable, External antenna x2, Quick start guide, Warranty card

Features Matrix

all software features at a glance

Wi-Fi

IPv6 MU-MIMO Encryption UTF-8 SSID Guest Network WPS MAC Filter Scheduler Airtime Fairness RADIUS Server Universal Beamforming Explicit Beamforming IGMP Snooping

QoS & Traffic

Parental Control Adaptive QoS Traditional QoS Bandwidth Monitor Bandwidth Limiter Traffic Monitor Traffic Analyzer Website History Gaming Acceleration

WAN & LAN

Dual WAN 3G/4G Dongle Android Tethering Port Forwarding DDNS DMZ NAT Passthrough Port Triggering DHCP Server IPTV LAN Link Aggregation

USB & Storage

File System HDD Hibernation Safely Remove Download Master Media Server Time Machine Samba FTP Shared Folder Cloud Access

Admin & Security

Firewall Wake on LAN SSH Access Config Backup/Restore Diagnosis Tools Feedback System System Log Antivirus Site Blocking Auto Firmware Update
