Synology WRX560

Name: Synology WRX560
Brand: Synology
SKU: WRX560

Released Nov 2022

A dual-band Wi-Fi 6 router built for device-laden households. It features a quad-core 1.4 GHz processor, a configurable 2.5GbE WAN/LAN port, and runs the powerful Synology Router Manager (SRM) with comprehensive parental controls and seamless mesh networking.

Wi-Fi

WiFi 6 (802.11ax)

RAM

512 MB

CPU Cores

LAN Ports

At a glance

Highlights

Wi-Fi WiFi 6 (802.11ax)

Supports IPv4, IPv6, WiFi (802.11a), WiFi (802.11b), WiFi (802.11g), WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax)

Dual-band

2.4 GHz · 5 GHz

3 × Gigabit LAN

1 Gigabit WAN port

Mesh: Yes, Primary and Node

Compatible with mesh networking

Built-in VPN

Client: L2TP, OpenVPN, PPTP · Server: IPSec, L2TP, OpenVPN, PPTP

Every detail

Full Specifications

General

9 specs

Manufacturer

Synology

Model

WRX560

Full Name

Synology WRX560

Homepage

Open website

Release Date

2022-11-02

Currently Sold

Yes

Manufacturer Support

Yes

Operating System

Synology Router Manager (SRM)

Mesh Integration

Yes, Primary and Node

Hardware

4 specs

Processor Speed (MHz)

1400

CPU Cores

RAM (MB)

512

Internal Antennas

Connectivity

13 specs

Network Standards

IPv4 IPv6 WiFi (802.11a) WiFi (802.11b) WiFi (802.11g) WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax)

Operating Modes

Accesspoint Router

2.4 GHz Support

Yes

5 GHz Support

Yes

6 GHz Support

Gigabit WAN Ports

Gigabit LAN Ports

LAN Aggregation

WAN Aggregation

USB Ports

USB-A (3.2) (1)

WAN Connection Types

Automatic IP PPPOE PPTP Static IP

Cable Modem

Fibre Modem

Core Features

7 specs

VPN Clients

L2TP OpenVPN PPTP

VPN Servers

IPSec L2TP OpenVPN PPTP

Mobile App

DS router

WPS Button

Yes

Reset Button

Yes

Power Switch

Yes

LED Switch

Physical

12 specs

Weight (g)

1350.00

Length (mm)

66.00

Width (mm)

194.00

Height (mm)

233.00

110V Power Supply

Yes

220V Power Supply

Yes

Horizontal Positioning

Vertical Positioning

Yes

Wall Mountable

Package Content

Main Unit X 1, AC Power Adapter X 1, RJ-45 LAN Cable X 1, Quick Installation Guide X 1

Warranty (Years)

Warranty Details

The warranty period starts from the purchase date as stated on your purchase receipt.

Features Matrix

all software features at a glance

Wi-Fi

IPv6 MU-MIMO Encryption UTF-8 SSID Guest Network WPS MAC Filter Scheduler Airtime Fairness RADIUS Server Universal Beamforming Explicit Beamforming IGMP Snooping

QoS & Traffic

Parental Control Adaptive QoS Traditional QoS Bandwidth Monitor Bandwidth Limiter Traffic Monitor Traffic Analyzer Website History Gaming Acceleration

WAN & LAN

Dual WAN 3G/4G Dongle Android Tethering Port Forwarding DDNS DMZ NAT Passthrough Port Triggering DHCP Server IPTV LAN Link Aggregation

USB & Storage

File System HDD Hibernation Safely Remove Download Master Media Server Time Machine Samba FTP Shared Folder Cloud Access

Admin & Security

Firewall Wake on LAN SSH Access Config Backup/Restore Diagnosis Tools Feedback System System Log Antivirus Site Blocking Auto Firmware Update
